Zemic L6N Serisi Avrupa Menşeli Loadcell

Stok Kodu: 0

Whatsapp Sipariş

Açıklama:

Detaylar

Product L6N Load Cell

L6N

Platform tipi alüminyum IP65 yük hücresi. Renksiz olarak anodize edilmiştir. Fiyat hesaplamalı teraziler, tezgah terazileri gibi teraziler için uygundur. Tavsiye edilen platform boyutları: 350 x 400 mm

Features L6N Load Cell:

Aluminium IP65 single point Load Cell.
Colorless anodized, suitable for pricing scales, bench scales, etc.
Recommended platform size: 350x400mm

Products specification

◆L6N load cells are available in the capacities 3kg to 100kg.
◆Alumium construction with parallel beam.
◆Silicon adhesive sealed, surface anodized and anti-corrosion.
◆Intergral structure and easy installation.
◆Suitable for electronic balance and other electronic
weighing devices.

Features
◆Capacity:3kg to 100kg .
◆High accuracy.
◆Max. platform size:
400x400mm.
◆With OIML approval.

Specifications

Capacity	(kg)	3/5/8/10/15/20/30/40/50/75/100
Accuracy		C3
Approvals		OIML R60 C3
Maximum number of verification intervals	n max	3000
Minimum load cell verification interval	v min	Emax/7000
Combined error	(%FS)	≤±0.020
Creep	(%FS/30min)	≤±0.0167
Temperature effect on sensitivity	(%FS/10℃)	≤±0.0175
Temperature effect on zero	(%FS/10℃)	≤±0.020
Output sensitivity	(mv/v)	2.0±0.2
Input resistance	(Ω)	406±6
Output resistance	(Ω)	350±3
Insulation resistance	(MΩ)	≥5000(50VDC)
Zero balance	(%FS)	2
Temperature,compensated	(℃)	-10～+40
Temperature,operating	(℃)	-35～+65
Excitation, Recommended	(V)	5～12(DC)
Excitation,Max	(V)	18(DC)
Safe overload	(%FS)	150
Ultimate overload	(%FS)	300
Corner correction		0.02% load value/100mm

Outline Dimension mm(inch)

More detailed information about L6N
